DC5xD MK3 GENSET CONTROLLER USER MANUAL
9
Descriptions of terminal connection
Function
Description
Cable
cross
sectional
area
Battery Negative Input B-
Controller power supply input B-.
2.5mm
2
Battery Negative Input B+
Controller power supply input B+.
2.5mm
2
Emergency Stop Input
B+ voltage input is active, and connected to
2.5mm
2
