Mebay DC5 D MK3 Series User Manual

DC5xD MK3 GENSET CONTROLLER USER MANUAL
10
emergency stop normal closed button.
4
Fuel Output
+VE output, Max 16Amp
1.5mm
2
5
Crank Output
+VE output, Max 16Amp.
1.5mm
2
6
Aux. Ouput 1
+VE output, Max 5Amp.
1.5mm
2
7
Aux. Ouput 2 Normal close
Passive Output, Max 5Amp.
1.5mm
2
8
Aux. Ouput 2 Common
1.5mm
2
9
Aux. Ouput 2 Normal open
1.5mm
2
10
Aux.Output 3
Passive normally open output, Max 5Amp.
1.5mm
2
11
Aux.Output 3
1.5mm
2
12
Aux.Output 4
Passive normally open output, Max 5Amp.
1.5mm
2
13
Aux.Output 4
1.5mm
2
14
Charging excitation output
+VE output, Max 0.9Amp.
1.0mm
2
15
Speed sensor -
Use a shielded wire to connect the speed
sensor.
1.0mm
2
16
Speed sensor +
1.0mm
2
17
Temperature Sensor
Connect sensor input.
1.0mm
2
18
Oil pressure sensor
1.0mm
2
19
Fuel level sensor
1.0mm
2
20
Aux. Input 1
The grounding is valid according to the
function selection switch input.
1.0mm
2
21
Aux. Input 2
1.0mm
2
22
Aux. Input 3
1.0mm
2
23
Load CT Secondary L1
Current Transformer Secondary Rated 5A.
1.5mm
2
24
Load CT Secondary L2
1.5mm
2
25
Load CT Secondary L3
1.5mm
2
26
Load CT Secondary ICOM
Connect to the common.
1.5mm
2
27
Generator Voltage U
Connected to the power generation output R
phase.
1.0mm
2
28
Generator Voltage V
Connected to the power generation output S
phase.
1.0mm
2
29
Generator Voltage W
Connected to the power generation output T
phase.
1.0mm
2
30
Generator Voltage N2
Connected to the power generation output N
phase.
1.0mm
2
31
Mains Voltage R
Connected to the mains U phase.
1.0mm
2
32
Mains Voltage S
Connected to the mains V phase.
1.0mm
2
33
Mains Voltage T
Connected to the mains W phase.
1.0mm
2
34
Mains Voltage N1
Connected to the mains N phase.
1.0mm
2
38
Aux. Input 4
The grounding is valid according to the
function selection switch input.
1.0mm
2
39
Aux. Input 5
1.0mm
2
40
Sensor common GND
Connect the battery negative or outer.
1.0mm
2
