March 2022Section 12 - Fault Codes
81 Right Drive Motor Short 1930SE/Micro
Check the right drive motor and wiring, and motor
controller and wiring.
82
Right Brake Coil - Brakes
about 46 ohms
1930SE/Micro
Check battery voltage, contactor, wiring to brakes,
wiring to drive motors, motor controller and wiring.
All Models
Check battery voltage, right motor brake and
wiring, brake module and wiring, and contactor.
83
Left Brake Coil - Brakes
about 46 ohms
1930SE/Micro
Check battery voltage, contactor, wiring on brakes,
wiring to drive motors, motor controller and wiring.
All Models
Check battery voltage, left motor brake and wiring,
brake module and wiring, and contactor.
85
Brake Release Switch
Closed
1930SE/Micro
Turn brake release switch off. Replace brake
release switch.
86 Raised Brake Release Fault 1930SE Only Brake release switch engaged.
87 Brake Release Switch Fault 1930SE Only Brake release switch open.
89 Drive Motor Field Open All Models Check wiring on motors and motor controller.
91 Left Drive Motor Short All Models Check wiring to motor and motor controller.
92 Right Drive Motor Short All Models Check wiring to motor and motor controller.
99 Over 99% Load Warning All Models Platform has reached its weight capacity.
OL Platform Overloaded All Models
Remove the excess load immediately. > 2020 with
overload.
LL
Machine Tilted Beyond Safe
Limits Fault
All Models
Check to see if machine is tilted, then check wiring
to tilt sensor and the tilt sensor.
CH NOT A FAULT CODE All Models Indicates that key switch is in base controls.
Option Code For Machines
Model Older With Overload (Yellow Gate)
MICRO19®
To Serial #16900460 58
E2
From Serial #16900461 62
MICRO19XD® N/A E3
MICRO26® N/A 27
1930SE 58 --
2632SE, 3346SE, 4046SE, 4555SE 30, 26 A7
MME20, MME25 N/A A7
