Page 58 SE
AC
Slab Series - Service & Parts Manual
March 2022Section 15 - Chassis
Item Part Number Description Qty.
1 41010 Cover 1
2 41376 Screw 2
3 50590 Nut NHEX M12-1.75 2
4 53116 Screw SHCS M05-0.80 × 12 2
5 41010 Cover 1
6 41011 Bearing 4
7 41013 Washer 2
8 46351 Steer Yoke Weldment 1
9 44926 Pin 2
10 44927 Washer 2
11 41046 Bearing 4
12
41391 Tie Rod Weldment (2632AC) 1
41393 Tie Rod Weldment (3346AC, 4046AC) 1
41394 Tie Rod Weldment (4555AC) 1
13 41019 Bearing 2
14 50117 Screw HHCS M06-1.00 × 25 1
15 42449 Pin 1
16 50568 Nut NNYL M06-1.00 Flange 1
17 41007 Pin 1
18 43076 Straight Fitting 2
19 44928 Steer Cylinder Assembly 1
-- 41388 Seal Kit 1
20 43574 Circlips 1
21 41009 Pin 1
22 53447 Screw HHCS 3/8-16 × 1 1/2 14
23 53316 WSHR 3/8 Spring Washer 12
24 53317 WSHR 3/8 Standard Flat Narrow Washer 12
25 46352 Steer Yoke Weldment 1
26 46353 Motor Cover 1
27 50000 WSHR M06 Standard Flat Washer 4
28 53046 WSHR M06 Spring Washer 4
29 53104 Screw HHCS M06-1.00 × 12 4
30 46354 Drive Motor Assembly 2
-- 46355 Reducer 1
-- 46356 Motor 1
-- 46357 Brake 1
31 46358 Wheel 2
32 46238 Wheel Bolt 10
33 50313 Nut NNYL M08-1.25 Flange 1
34 53257 Screw HHCS M08-1.25 × 20 Serrated Flange 2
35 41425 Hose Clamp Support 1
36 46240 Hose Clamp 1
37 41416 Hose Clamp 1
38 41415 Base Plate 1
39 53401 Screw HHCS M08-1.25 × 90 1
