Page 60 SE
AC
Slab Series - Service & Parts Manual
March 2022Section 15 - Chassis
Item Part Number Description Qty.
1 44888 Pothole Guard Weldment 1
2 41049 Roller 2
3 50050 Nut NNYL M12 × 1.75 8
4 43568 Bearing 4
5 41604 Pin 4
6 44889 Seal 2
7 43569 Pothole Hole Pusher Assembly 2
8 41222 Bearing 4
9 41210 Bearing 4
10 41807 Lock Clasp 1
11 47093 Linkage Weldment 1
12 50005 WSHR M20 Standard Flat Washer 2
13 50052 Nut NNYL M20 × 2.50 2
14 41808 Lock Clasp 1
15 53194 Screw HHCS M08-1.25 × 16 Serrated Flange 4
16 46242 Limit Switch, Pothole 2
17 53038 WSHR M05 Standard Flat Washer 8
18 53171 Screw SHCS M05-0.80 × 30 4
19 53173 Screw SHCS M05-0.80 × 10 4
20 53043 WSHR M05 Spring Washer 4
21 41035 Switch Cover 2
22 44890 Pothole Guard Weldment 1
23 44891 Pothole Guide 1
24 50429 Screw HHCS M10-1.50 × 25 Serrated Flange 4
25 41040 Washer 2
26 41046 Bearing 4
27 53283 Set Screw M05-0.80 × 10 Cone Point 2
28 47092 Linkage Weldment 1
29 41048 Pin 2
30 41047 Pin 2
31 41214 Bearing 4
32 44892 Pothole Link Plate 2
33 50003
WSHR M12 Standard Flat Washer 4
34 41045 Gas Shock 2
35 43573 Gas Shock Strut 2
To Next Page
