Page 66 SE
AC
Slab Series - Service & Parts Manual
March 2022Section 15 - Chassis
Item Part Number Description Qty.
1 53451 Screw THMS M05-0.80 × 8 2
2 46363 300A Fuse Assembly 1
-- 46364 300A Fuse 1
-- 46248 Fuse Block 1
3 46263 Battery Alarm 1
4 50568 Nut NNYL M06-1.00 Flange 2
5 53264 Screw PHMS M06-1.00 × 20 2
6 41066 Threaded Rod 1
7 50048 Nut NNYL M08 × 1.25 1
8 41060 Hinge Pin 2
9 41046 Bearing 4
10 41062 Bumper (2632AC, 3346AC, 4046AC) 1
11 50002 WSHR M10 Standard Flat Washer 2
12 50519 Screw SHCS M10-1.50 × 55 1
13 41019 Bearing 2
14 44936 Circlips 2
15 50311 Nut NNYL M10-1.50 Flange 1
16
46365 Battery Tray Weldment (2632AC) 1
46366 Battery Tray Weldment (3346AC, 4046AC) 1
46367 Battery Tray Weldment (4555AC) 1
17
46244 Battery (2632AC) 4
46368 Battery (3346AC) (Need To Install The Liner 46369) 4
46370 Battery (4046AC, 4555AC) 4
18 42071 Power Switch 1
19 42896 Latch (Left) 1
20 53255 Screw HHCS M06-1.00 × 20 Serrated Flange 2
21 41068 Handle Hole Ring 1
22 53265 Screw THMS M05-0.80 × 10 2
23 42903 Charger 1
24 53318 Screw PHMS M06-1.00 × 12 4
To Next Page
