Mec 4046SE - Page 73

Page 68 SE
AC
Slab Series - Service & Parts Manual
March 2022Section 15 - Chassis
Item Part Number Description Qty.
1 REF Ground Control and Cover Assembly (Refer To Page 71) 1
2 REF Hydraulic Tank Assembly (Refer To Page 77) 1
3 50313 Nut NNYL M08-1.25 Flange 2
4 46323 Hydraulic Tray Weldment 1
5 41068 Handle Hole Ring 1
6 53231 Screw PHMS M06-1.00 × 16 4
7 46250 Motor Controller 1
8 50000 WSHR M06 Standard Flat Washer 3
9 46251 Cover 1
10 53448 Screw BHCS M06-1.00 × 16 3
11 53255 Screw HHCS M06-1.00 × 20 Serrated Flange 2
12 41067 Latch (Right) 1
13 50561 Screw CSCS M06-1.00 × 20 1
14 53071 Screw CSCS M08-1.25 × 35 2
15 53265 Screw THMS M05-0.80 × 10 2
16 46252 Relay 1
17 41120 Bumper 1
18 REF Pump Motor Assembly (Refer To Page 83) 1
19 53282 Screw CSCS M08-1.25 × 20 4
20 50386 Screw CSCS M06-1.00 × 25 3
21 50568 Nut NNYL M06-1.00 Flange 3
22 41077 Filter Assembly 1
-- 41078 Filter Element 1
23 43576 Straight Fitting 2
24 46324 Filter Bracket 1
25 53256 Screw HHCS M06-1.00 × 16 Serrated Flange 2
26 REF Function Manifold (Refer To Page 141) 1
27 53257 Screw HHCS M08-1.25 × 20 Serrated Flange 4
28 43574 Circlips 2
29 41037 Bearing 4
30 41814 Washer 2
31 41813 Hinge Pin 2
REF - Reference
