Page 70 SE
AC
Slab Series - Service & Parts Manual
March 2022Section 15 - Chassis
Item Part Number Description Qty.
1 41060 Hinge Pin 2
2 41046 Bearing 4
3 53067 Screw SHCS M05-0.80 × 40 2
4 53043 WSHR M05 Spring Washer 2
5 53038 WSHR M05 Standard Flat Washer 2
6 REF Ground Control Assembly (Refer To Page 75) 1
7 REF Ground Control Cover Assembly (Refer To Page 73) 1
8 REF Hydraulic Tank Assembly (Refer To Page 79) 1
9 53448 Screw BHCS M06-1.00 × 16 2
10 50000 WSHR M06 Standard Flat Washer 6
11 41068 Handle Hole Ring 1
12 41067 Latch (Right) 1
13 53255 Screw HHCS M06-1.00 × 20 Serrated Flange 2
14 41073 Cover 1
15 53318 Screw PHMS M06-1.00 × 12 4
16 REF Motor Controller Assembly (Refer To Page 81) 1
17 50561 Screw CSCS M06-1.00 × 20 2
18
46371 Hydraulic Tray Weldment (2632AC, 3346AC, 4046AC) 1
46372 Hydraulic Tray Weldment (4555AC) 1
19 53434 Screw CSCS M08-1.25 × 16 4
20 53435 Screw CSCS M08-1.25 × 25 4
21 REF Pump Motor Assembly (Refer To Page 85) 1
22 50001 WSHR M08 Standard Flat Washer 4
23 50048 Nut NNYL M08 × 1.25 4
24 53256 Screw HHCS M06-1.00 × 16 Serrated Flange 2
25 43576 Straight Fitting 2
26 41077 Filter Assembly 1
-- 41078 Filter Element 1
27 50568 Nut NNYL M06-1.00 Flange 3
28 50386 Screw CSCS M06-1.00 × 25 3
29 46373 Controller Bracket 1
30 46271 Motor Controller 1
31 53046 WSHR M06 Spring Washer
4
32 53124 Screw SHCS M06-1.00 × 20 4
33 REF Function Manifold (Refer To Page 143) 1
34 53257 Screw HHCS M08-1.25 × 20 Serrated Flange 4
35 44936 Circlips 2
36 41019 Bearing 2
37 50519 Screw SHCS M10-1.50 × 55 (2632AC, 3346AC, 4046AC) 1
38 50002 WSHR M10 Standard Flat Washer (2632AC, 3346AC, 4046AC) 1
39 41062 Bumper (2632AC, 3346AC, 4046AC, 4555AC) 1
40 50311 Nut NNYL M10-1.50 Flange (2632AC, 3346AC, 4046AC) 1
