Page 72 SE
AC
Slab Series - Service & Parts Manual
March 2022Section 15 - Chassis
Item Part Number Description Qty.
1 46255 Ground Control Bracket 1
2 53281 Nut NNYL M05-0.80 Flange 3
3 46256 Hinge 1
4 53224 Screw THMS M05-0.80 × 12 3
5 53279 Screw CSCS M05-0.80 × 12 5
6 46257 Cover 1
7 REF Ground Control Assembly (Refer To Page 75) 1
8 53038 WSHR M05 Standard Flat Washer 2
9 53043 WSHR M05 Spring Washer 2
10 53067 Screw SHCS M05-0.80 × 40 2
REF - Reference
To Next Page
