Page 82 SE
AC
Slab Series - Service & Parts Manual
March 2022Section 15 - Chassis
Item Part Number Description Qty.
1 53124 Screw SHCS M06-1.00 × 20 4
2 53046 WSHR M06 Spring Washer 4
3 50000 WSHR M06 Standard Flat Washer 4
4 46250 Motor Controller 1
5 53265 Screw THMS M05-0.80 × 10 1
6 46252 Relay 1
7 53276 Screw PHMS M04-0.70 × 8 2
8 53062 WSHR M04 Spring Washer 2
9 50284 WSHR M04 Standard Flat Washer 2
10 41331 DC Contactor 1
11 46377 Mounting Plate 1
