Page 88 SE
AC
Slab Series - Service & Parts Manual
March 2022Section 15 - Chassis
Item Part Number Description Qty.
1 46321 Wheel 2
2 46238 Bolt 10
3 41328 Cap 2
4 53282 Screw CSCS M08-1.25 × 20 16
5 41025 Bearing Seat 2
6 41002 Spacer 2
7 43585 Cotter Pin 2
8 43586 Spindle 2
9 46325 Ladder 1
10 50429 Screw HHCS M10-1.50 × 25 Serrated Flange 4
11 41003 Ground Strap 1
12 53260 Screw HHCS M06-1.00 × 10 Serrated Flange 1
13 53290 Screw HHCS M12-1.75 × 65 Flange 8
14 REF Charger Assembly (Refer To Page 91) 1
15 53194 Screw HHCS M08-1.25 × 16 Serrated Flange 2
16 53261 Nut NNYL M12-1.75 Flange 8
17 43588 Seal 2
18 41029 Bearing 2
19 41024 Bearing 2
20 41304 Washer 2
21 53262 Castle Nut M22 × 1.50 2
REF - Reference
