Page 90 SE
AC
Slab Series - Service & Parts Manual
March 2022Section 15 - Chassis
Item Part Number Description Qty.
-- REF Rear Wheel Assembly (Includes Item 1-6 And 15-22) /
1 41328 Cap 2
2 41025 Bearing Seat 2
3 53262 Castle Nut M22 × 1.50 2
4 41304 Washer 2
5 41024 Bearing 2
6 41029 Bearing 2
7 41002 Spacer 2
8 53282 Screw CSCS M08-1.25 × 20 16
9 53047 Screw HHCS M14-2.00 × 35 4
10 53048 WSHR M14 Spring Washer 4
11 53049 WSHR M14 Standard Flat Washer 4
12
41374 Ladder (2632AC) 1
41464 Ladder (3346AC) 1
41004 Ladder (4046AC, 4555AC) 1
13 53260 Screw HHCS M06-1.00 × 10 Serrated Flange 1
14 41003 Ground Strap 1
15 53438 Screw HHCS M12-1.75 × 100 Flange 8
16 41021 Terminal Pad 2
17 41022 Spindle 2
18 53261 Nut NNYL M12-1.75 Flange 8
19 43588 Seal 2
20 43585 Cotter Pin 2
21 46358 Wheel 2
22 46238 Bolt 10
REF - Reference
