Page 92 SE
AC
Slab Series - Service & Parts Manual
March 2022Section 15 - Chassis
Item Part Number Description Qty.
1 42903 Charger 1
2 46262 Charger Bracket Weldment 1
3 53221 Screw CSCS M04-0.70 × 16 2
4 41575 Plug 1
5 53263 Screw THMS M04-0.70 × 8 2
6 43591 Plug Bracket 1
7 50568 Nut NNYL M06-1.00 Flange 6
8 53264 Screw PHMS M06-1.00 × 20 2
9 50284 WSHR M04 Standard Flat Washer 2
10 50285 Nut NNYL M04 × 0.70 2
11 46263 Battery Alarm 1
12 53432 Screw HHCS M06-1.00 × 25 Serrated Flange 4
