Page 94 SE
AC
Slab Series - Service & Parts Manual
March 2022Section 15 - Chassis
Item Part Number Description Qty.
1 53449 Screw HHCS M05-0.80 × 10 Flange 4
2 44895 Cover 1
3 53223 Screw THMS M05-0.80 × 16 6
4 41309 Beacon Cover 1
5 46264 Beacon 1
6 41051 Bearing 2
7 53067 Screw SHCS M05-0.80 × 40 2
8 53038 WSHR M05 Standard Flat Washer 8
9 53281 Nut NNYL M05-0.80 Flange 2
10 46265 Limit Switch, Lift Down 1
11 43594 Signal Plate 1
12 50423 Screw SHCS M04-0.70 × 12 4
13 53062 WSHR M04 Spring Washer 4
14 50284 WSHR M04 Standard Flat Washer 4
15 43593 Switch Bracket 1
16 53043 WSHR M05 Spring Washer 6
17 50359 Screw SHCS M05-0.80 × 16 6
18 46326 Frame Weldment 1
19 46267 Rotary Sensor 1
20 53356 Screw SHCS M05-0.80 × 25 4
21 46268 Sensor Bracket 1
22 46269 Sensor Cover 1
23 53265 Screw THMS M05-0.80 × 10 2
24 46270 Sheath 2 1
25 46271 Motor Controller 1
26 46272 Cover 1
27 53266 Screw THMS M05-0.80 × 6 4
To Next Page
