Slab Series - Operator’s Manual
November 2022Section 3 - Specications
Specications - 4046SE & 4555SE
4046SE 4555SE
Working Height*
Indoor 44.7 ft 13.6 m 51 ft 15.7 m
Outdoor 36 ft 11 m 41 ft 12.5 m
Platform Height
Indoor 38.7 ft 11.8 m 45 ft 13.7 m
Outdoor 30 ft 9.2 m 35 ft 10.7 m
Maximum Drive Height 38.7 ft 11.8 m 45 ft 13.7 m
Stowed Height
Top Guardrail 102 in 2.6 m 102 in 2.6 m
Rails Folded 79 in 2.0 m 79 in 2.0 m
Platform Floor 58 in 1.48 m 58 in 1.48 m
Guardrail Height 43.5 in 1.11 m 43.5 in 1.11 m
Toeboard Height 6 in 15 cm 6 in 15 cm
Machine Weight** (Unloaded) 7,000 lb 3,180 kg 7,600 lb 3,450 kg
Maximum Lift Capacity 700 lb 317 kg 600 lb 272 kg
Deck Extension Capacity 1 Person / 250 lb (113 kg) 1 Person / 250 lb (113 kg)
Maximum
Occupants
Indoor 2 Persons 2 Persons
Outdoor 1 Person 1 Person
Manual Force
Indoor 90 lbs 400 N 90 lbs 400 N
Outdoor 45 lbs 200 N 45 lbs 200 N
Length-Stowed (Overall) 98 in 2.5 m 112 in 2.85 m
Length-Stowed (Ladder Removed) 89.5 in 2.27 m 104 in 2.65 m
Platform Length (Extended) 124.5 in 3.16 m 139 in 3.53 m
Platform Length (Retracted) 89.5 in 2.27 m 104 in 2.65 m
Width (Overall) 47 in 1.2 cm 55 in 1.4 cm
Platform Width (Outside) 44 in 1.12 cm 44 in 1.12 cm
Wheel Base 74 in 1.87 m 87 in 2.22 m
Turning Radius - Inside 0 in 0 cm 0 in 0 cm
Ground Clearance - Stowed 4 in 10 cm 4 in 10 cm
Ground Clearance - Elevated 0.7 in
2 cm 0.7 in 2 cm
Drive Speed
(Proportional)
Stowed 0-2.5 mph 0-4 km/h 0-2.5 mph 0-4 km/h
Raised Or Extended 0-0.5 mph 0-0.8 km/h 0-0.5 mph 0-0.8 km/h
Gradability 25%/14° 25%/14°
Maximum Side Slope - Stowed 5° 5°
Tilt Sensor Settings 2° side-to-side, 3° fore-and-aft 2° side-to-side, 3° fore-and-aft
Ground Pressure/Wheel 167 psi 11.7 kg/cm
2
256 psi 18 kg/cm
2
Maximum Wheel Load 2,250 lb 1,020 kg 2,400 lb 1,090 kg
Occupied Floor Pressure 255 psf 1,240 kg/m
2
194 psf 947 kg/m
2
Maximum Operating Wind Speed 28 mph, 12.5 m/sec (45 km/h) 28 mph, 12.5 m/sec (45 km/h)
Tire Size 15 × 5 inch/381 × 127 mm 15 × 5 inch/381 × 127 mm
Wheel Bolt Torque 43 ft-lb / 58.3 Nm 43 ft-lb / 58.3 Nm
Hydraulic Pressure 3,000 psi/ 207 bar 3,000 psi/ 207 bar
Power System Voltage 24 Volt DC / 300Ah 24 Volt DC / 300Ah
Battery Charger
Input 110-230 V AC, 50-60 Hz 110-230 V AC, 50-60 Hz
Output 24 Volt DC 24 Volt DC
Batteries Four 12-Volt deep cycle, 300 Ah Four 12-Volt deep cycle, 300 Ah
Chassis Inclination 1.5 Side 3.0 Inline 1.5 Side 3.0 Inline
Meets requirements of ANSI A92.20-2020 and CSA B354.6-2019.
*Working Height adds 6 feet (2 m) to platform height.
**Weight may increase with certain options.
†Sheet material weight is part of the total platform capacity. This may limit capacity to one occupant.
