March 2014
Page E-25
“4069RT” Parts Section
• as req: as required • INCL: Included with assembly • NS: Not a Stock item • REF: Reference only
Hoses -- Lift Cylinder Drain, Current Machines
ITEM
PART
NUMBER
QTY. DESCRIPTION
1 50959 as req Hose, 5/16” Fuel Line
2 50959 as req Hose, 5/16” Fuel Line
3 HDW91249 1 Fitting, 5/16” Barbed Tee
4 50959 as req Hose, 5/16” Fuel Line
5 HDW90945 2/4 Fitting, 5/16” Nipple
6 50905 1/2 Fitting, MJ-MJ-MPT-5-5-4
7 50959 as req Hose, 5/16” Fuel Line
8 HDW6727 2 Fitting, 5/16 Barbed 90
