“4069RT” Service and Parts ManualMarch 2014
Page II
M
ACHINE
S
PECIFICATIONS
4069RT
Working Height* 46 ft 14 m
Platform Height 40 ft 12 m
Maximum Drive Height 40 ft 12 m
Stowed Height Top Guardrail 95.5 in. 2.43 m
Rails Folded 64 in. 1.63 m
Platform Floor 51 in. 1.3 m
Guardrail Height 43.5 in. 1.11 m
Toeboard Height 6 in. 15 cm
Machine Weight** (Unloaded) 11,000 lb 4,990 kg
Lift Capacity Total 900 lb 410 kg
Platform 600 lb 274 kg
Sheet Material Rack 300 lb 136 kg
Deck Extension Capacity 1 Person / 250 lb (113 kg)
Maximum Occupants 2
Length-Stowed (Overall) 126 in. 3.2 m
Length-Stowed (Without Step) 125 in. 3.18 m
Length-Stowed, with optional Outriggers 145 in. 3.64 m
Platform Length (Extended) 166 in. 4.22 m
Platform Length (Retracted) 118 in. 3 m
Width (Overall) 69 in. 1.75 m
Platform Width (Outside) 59 in. 1.5 cm
Sheet Rack Width 7 in. 18 cm
Wheel Base 94.5 in 2.4 m
Turning Radius--Inside 79 in. 2 m
Ground Clearance 10 in 25 cm
Drive Speed (Proportional) Platform Stowed 0-3.4 mph 0-5.5 km/h
Platform Elevated† 0-.5 mph max.† 0-.8 km/h max.†
Gradability 40%/21.8°
Breakover Angle 42%/23°
Optional Outrigger Range Of Motion 10° side to side
Maximum Ground Pressure, Wheel 123 psi
8.6 kg/cm
2
Maximum Ground Pressure, Outrigger Pad 56 psi
3.9 kg/cm
2
Maximum Wheel Load 3540 lb 1605 kg
Maximum Operating Wind Speed 28 mph / 12.5 m/sec (45 km/h)
Tire Size 26" x 12" / 66 cm x 33 cm
Tire Pressure 55 psi
Wheel Bolt Torque 55 ft/lb 74.6 Nm
Hydraulic Pressure Drive System 3500 psi/ 240 bar
Lift System 3200 psi / 220 bar
Hydraulic Fluid Capacity 14 gal / 53 liter
System Voltage 12 Volt DC
Fuel Capacity 15 gal/ 57 liter
Battery Type 31 1000CCA
Engine Diesel -- Kubota D1105 24.8 HP (18.8 kW) Tier 4
Dual Fuel -- Kubota DF752, 20HP (14.9 kW)
Meets applicable requirements of ANSI A92.6-2006.
*Working Height adds 6 feet (2 m) to platform height. **Weight may increase with certain options.
†Drive speed while elevated is inversely proportional to platform height; the higher the platform is, the
lower the maximum elevated drive speed. The machine is driveable at full height.
