Emergency Systems and Procedures
IF THE CONTROL SYSTEM FAILS WHILE THE PLATFORM IS ELEVATED,
HAVE AN EXPERIENCED OPERATOR USE THE EMERGENCY LOWERING
PROCEDURE TO SAFELY LOWER THE PLATFORM.
DO NOT ATTEMPT TO CLIMB DOWN ELEVATING ASSEMBLY.
Emergency Stop
ART_3353
The machine is equipped with an EMERGENCY STOP switch at the base
controls and the platform control box.
Press the EMERGENCY STOP switch at any time to stop all machine
functions.
Pull switch to reset.
Either switch will stop all machine functions.
Both switches must be reset or machine will not operate.
•
•
•
•
Emergency Lowering
ART_4986
Emergency
Lowering
Knob
The Emergency Lowering System is used to lower the platform in case of power failure.
To lower the platform, pull the Emergency Lowering Knob, located near the Base Control panel.
