Page 43 Micro 19-XD - Service & Parts Manual
June 2020Section 13 - Chassis
Item Part Number Description Qty.
1 42422 Hydraulic Power Unit (Refer To Page 44) 1
2 41413 Nut 1
3 41296 Straight Fitting 3
4 42491 Ground Control Cover 1
5 53350 Wing Nut M06-1.00 4
6 50000 WSHR M06 Standard Flat 4
7 44019 Battery 2
8 41074 Alarm 1
9 53281 NNYL M05-0.80 Flange 8
10 53351 PHMS M05-0.80 × 16 8
11 43987 Towline 1
12 53352 CSCS M06-1.00 × 10 4
13 42430 Towline Bracket 1
14 53273 HHCS M06-1.00 × 14 Serrated Flange 2
15 42431 Press Plate 1
16 50568 NNYL M06-1.00 Flange 9
17 REF Motor Controller Assembly (Refer To Page 46) 1
18 50359 SHCS M05-0.80 × 16 4
19 53043 WSHR M05 Spring Washer 10
20 53038 WSHR M05 Standard Flat 10
21 41075 Horn 1
22 43977 Latch 2
23 53264 PHMS M06-1.00 × 20 4
24 53353 PHMS M06-1.00 × 25 4
25 REF Ground Control Assembly (Refer To Page 48) 1
26 53348 THMS M04-0.70 × 10 8
27 43988 Battery Tray Weldment 1
28 53354 PHMS M05-0.80 × 10 2
29 41575 Plug 1
30 53263 THMS M04-0.70 × 8 2
31 41255 Glide Track 2
32 42071 Emergency Switch 1
33 42904 Charger 1
34 53222
PHMS M05-0.80 × 8 4
35 53225 CSCS M10-1.50 × 30 2
36 41337 Bracket 1
37 50002 WSHR M10 Standard Flat 2
38 53054 WSHR M10 Spring Washer 2
39 50127 SHCS M10-1.50 × 30 2
REF - Reference
