Page 45 Micro 19-XD - Service & Parts Manual
June 2020Section 13 - Chassis
Item Part Number Description Qty.
1 42426 Tank 1
2 43784 Tank Cover 1
3 42424 Motor 1
4 44009 Relief Valve Lift 1
5 42425 Pump 1
6 44010 Filter Web 1
7 43776 Plug 1
8 43777 Washer 1
9 44011 Coil 3
10 44013 Check Valve 1
11 41245 Solenoid Valve Spool Lift 1
12 42427 Pressure Compensation Valve 1
13 44012 Relief Valve Steer 1
14 41246 Solenoid Valve Spool Steer 1
