Page 47 Micro 19-XD - Service & Parts Manual
June 2020Section 13 - Chassis
Item Part Number Description Qty.
1 42431 Mounting Plate 1
2 41610 Motor Controller 1
3 50000 WSHR M06 Standard Flat 4
4 53046 WSHR M06 Spring Washer 4
5 50028 HHCS M06-1.00 × 20 3
6 50327 HHCS M06-1.00 × 35 1
7 42432 200A Fuse Assembly 1
-- 44014 200A Fuse 1
-- 41092 Fuse Seat 1
8 53355 PHMS M05-0.80 × 14 2
9 53222 PHMS M05-0.80 × 8 2
10 53043 WSHR M05 Spring Washer 2
11 53038 WSHR M05 Standard Flat 2
12 41331 DC Contactor 1
