Page 51 Micro 19-XD - Service & Parts Manual
June 2020Section 13 - Chassis
Item Part Number Description Qty.
1 53281 NNYL M05-0.80 Flange 2
2 53265 THMS M05-0.80 × 10 7
3 42406 Beacon Bracket 1
4 41310 Beacon 1
5 41309 Beacon Cover 1
6 53356 SHCS M05-0.80 × 25 2
7 53038 WSHR M05 Standard Flat 8
8 43978 Lock 2
9 53043 WSHR M05 Spring Washer 6
10 53173 SHCS M05-0.80 × 10 6
11 41197 Limit Switch 2
12 53065 SHCS M04-0.70 × 30 6
13 53113 SHCS M04-0.70 × 16 4
14 41315 Switch Cover 1
15 50423 SHCS M04-0.70 × 12 4
16 53062 WSHR M04 Spring Washer 6
17 50284 WSHR M04 Standard Flat 6
18 41198 Switch Cover 1
19 42401 Cover 1
20 43995 Frame Weldment 1
21 50289 HHCS M06-1.00 × 40 2
22 41098 Tilt Sensor 1
23 42403 Sensor Bracket 1
24 50568 NNYL M06-1.00 Flange 2
25 41003 Ground Strap 1
26 53273 HHCS M06-1.00 × 14 Serrated Flange 1
27 42405 Ladder 1
28 50001 WSHR M08 Standard Flat 4
29 53055 WSHR M08 Spring Washer 4
30 50031 HHCS M08-1.25 × 25 4
31 53223 THMS M05-0.80 × 16 2
32 41257 Bearing 2
33 41194 Sensor Bracket 1
34 41195
Rotary Sensor 1
35 42885 Sensor Cover 1
