Mec Micro 19-XD - Page 57

Page 53 Micro 19-XD - Service & Parts Manual
June 2020Section 14 - Scissor
Item Part Number Description Qty.
1 42437 Circlips 36
2 41354 Washer 34
3 41349 Pin 6
4 41576 Pin 1
5 41256 Platform Slider 2
6 43744 Cable Bridge 1
7 41577 Pin 10
8 53123 SHCS M06-1.00 × 25 4
9 53046 WSHR M06 Spring Washer 4
10 50000 WSHR M06 Standard Flat 4
11 42439 Lock Plate 2
12 42438 Cable Bridge 1
13 42440 Pin 1
14 REF Upper Lift Cylinder Assembly (Refer To Page 68) 1
15 42442 Cable Bridge 2
16 41262 Safety Arm Bushing 2
17 41263 Safety Arm 2
18 53255 HHCS M06-1.00 × 20 Serrated Flange 2
19 42443 Inner Arm 2 1
20 43996 Inner Arm 1 1
21 53357 HHCS M06-1.00 × 55 Flange 4
22 50568 NNYL M06-1.00 Flange 6
23 42446 Bearing 28
24 41338 Pin 2
25 42447 Chassis Slider 2
26 42448 Outer Arm 1 1
27 50386 CSCS M06-1.00 × 25 2
28 41350 Pothole Pusher 1
29 41258 Pin 1
30 41112 Hydraulic Hoses Manifolds 1
31 43601 Hose (To Upper Lift Cylinder) 1
32 43997 Hose (To Lower Lift Cylinder) 1
33 44015 Hose (To Hydraulic Tank) 1
34 50561
CSCS M06-1.00 × 20 2
35 41114 Block 32
36 REF Lower Lift Cylinder Assembly (Refer To Page 66) 1
37 41345 Pin 2
38 53279 CSCS M05-0.80 × 12 3
39 41582 Collar 3
40 42452 Inner Arm 3 1
41 42453 Outer Arm 2 6
42 53256 HHCS M06-1.00 × 16 Serrated Flange 3
43 42449 Pin 3
44 42454 Pin 1
45 43998 Inner Arm 4 1
46 41287 Bearing 64
47 42456 Inner Arm 5 1
48 42457 Pin 1
49 42458 Outer Arm 5 1
REF - Reference
