Page 55 Micro 19-XD - Service & Parts Manual
June 2020Section 15 - Platform
Item Part Number Description Qty.
1 41357 Inserted Pin 4
2 53274 HHCS M06-1.00 × 50 Flange 6
3 43301 Rivet 4
4 50568 NNYL M06-1.00 Flange 7
5 44209 Upper Main Rail 2
6 44193 Lower Main Rail, Left 1
7 41120 Bumper 1
8 53224 THMS M05-0.80 × 12 1
9 44206 Lower Main Rail, Right 1
10 43618 Circlips 2
11 41131 Bearing 2
12 41269 Roller 2
13 53358 HHCS M08-1.25 × 50 Flange 4
14 50313 NNYL M08-1.25 Flange 8
15 53275 CSCS M08-1.25 × 45 8
16 41360 Roller Bracket 2
17 42461 Main Deck Weldment 1
18 53276 PHMS M04-0.70 × 8 2
19 41134 Clip 2
20 53273 HHCS M06-1.00 × 14 Serrated Flange 12
21 41127 Hinge A 1
22 41128 Hinge B 1
23 41273 Water-Proof Joint 1
24 41046 Bearing 2
25 41275 Sheath 1
26 42462 Washer 4
27 53359 HHCS M08-1.25 × 55 Flange 4
28 44194 Entry Gate 1
29 41278 Latch Handle 1
30 53360 HHCS M06-1.00 × 45 Flange 1
31 41277 Spring 1
32 95401 Lock Pin 2
33 44192 Door Rail 1
