Page 57 Micro 19-XD - Service & Parts Manual
June 2020Section 15 - Platform
Item Part Number Description Qty.
1 44217 Extension Deck Upper Rails Weldment 1
2 44020 Platform Control Assembly (Refer To Page 58) 1
3 50050 NNYL M12 × 1.75 2
4 93216 1.25” x .075/.083” Square Tube Cap 2
5 53307 WSHR Belleville 1.00 OD X 0.5 ID 16
6 50003 WSHR M12 Standard Flat 6
7 44176 Telescopic Rail 4
8 43319 Manual Box 1
9 53223 THMS M05-0.80 × 16 4
10 53281 NNYL M05-0.80 Flange 4
11 94981 Encased Magnetic Disc 2
12 95321 Nylon Plastic Countersunk Washer 2
13 50561 CSCS M06-1.00 × 20 2
14 95401 Plunger Pin 8
15 44187 Micro 19 Extension Deck Base 1
16 53148 WSHR M12 Spring Washer 2
17 50038 HHCS M12-1.50 × 25 2
18 41140 Platform Locking Device Assembly (Refer To Page 62) 1
19 53279 CSCS M05-0.80 × 12 8
20 41284 Slide Pad 2
21 53280 CSCS M08-1.25 × 55 8
22 41360 Roller Bracket 2
23 41141 Roller 2 2
24 41131 Bearing 2
25 43618 Circlips 2
26
44213 Outer Rails Weldment, Left Hand 1
44215 Outer Rails Weldment, Right Hand 1
27 41120 Bumper 5
28 53224 THMS M05-0.80 × 12 5
29 44245 Deck Guard Weldment 1
30 53337 SHSS 12 SHLDR DIA X 40 SHLDR LG X M10 SS 1
31 50006 WSHR M10 ZP Nordlock 1
32 44227 Deck Guard Hinge Bracket 1
33 44237 Deck Guard Latch Rest
1
