mecair MPS Series User Manual

5
6.3 TECHNICAL DRAWING 1: FILTERED TAPS
Silicon the seal well before
joining the parts
Wad
4 fixing holes
Ø 3
,
75
Self-tapping screws
Ø 4
,
25
Filter Wall
filt
50
50
25
25 45
39
39
Seal
Pressure Holes
(3÷5 Ø 4 central)
Otherwise 1 hole Ø 20
Ø 20
Positioned
U
p
ward
Fan
Dusty Air
Inlet
Pressure
Pressure
MPS
– +
Condesation outlets for
humid processes
Bag Filter
Filtered air
