Introduction
Specifications 1 - 3
1.Introduction
Pointing Device
Built-in Touchpad
Keyboard
Full-size “WinKey” keyboard (with numeric keypad)
Mini Card Slots
(Core i7-5500U/i5-5200U/i3-5010U)
Slot 1 for WLAN Module or WLAN and Bluetooth Combo
Module
Slot 2 for mSATA SSD
Or
(Factory Option) Slot 2 for M.2 3G/4G Module (require inter-
face adaptor card)
Mini Card Slots
(Core i3-5050U/3805U/3755U/3205U)
Slot 1 for WLAN Module or WLAN and Bluetooth Combo
Module
(Factory Option) Slot 2 for M.2 3G/4G Module (require inter-
face adaptor card)
Card Reader
Embedded Multi-In-1 Card Reader
MMC (MultiMedia Card) / RS MMC
SD (Secure Digital) / Mini SD / SDHC/ SDXC
MS (Memory Stick) / MS Pro / MS Duo
Interface
One HDMI-Out Port
One External Monitor Port
One Headphone-Out Jack
One Microphone-In Jack
One RJ-45 LAN Jack
One DC-in Jack
Two USB 3.0 Ports
Two USB 2.0 Ports
Communication
Built-In Gigabit Ethernet LAN
1.0M HD PC Camera Module
(Factory Option) 3G or 4G M.2 Module
WLAN/ Bluetooth Half Mini-Card Modules:
(Factory Option) Intel® Wireless-AC 3160 Wireless LAN
(802.11ac) + Bluetooth 4.0
(Factory Option) Intel® Wireless-N 7260 Wireless LAN
(802.11b/g/n) + Bluetooth 4.0
(Factory Option) Third-Party Wireless LAN (802.11b/g/n)
(Factory Option) Third-Party Wireless LAN (802.11b/g/n) +
Bluetooth 4.0
Environmental Spec
Temperature
Operating: 5
°C - 35°C
Non-Operating: -20°C - 60°C
Relative Humidity
Operating: 20% - 80%
Non-Operating: 10% - 90%
Power
Full Range AC/DC Adapter
AC Input: 100 - 240V, 50 - 60Hz
DC Output: 19V, 2.1A (40W)
Removable 4 Cell Smart Lithium-Ion Battery Pack, 32WH
(Factory Option) Removable 4 Cell Smart Lithium-Ion Bat-
tery Pack, 44WH
Dimensions & Weight
374mm (w) * 258.5mm (d) * 12 - 24.7mm (h)
2.1kg (Barebone with ODD and 32WH Battery)
