MechMaxx P4206 - To-Scale Hardware

TO-SCALE HARDWARE
TO-SCALE HARDWARE
10
www. mechmaxx.com
Hardware graphics are printed at 1:1 scale for ease of identification. Simply place the hardware over the image in the
tables to verify it is the correct size.
M10 X 25mm
Hex bolt
8X
M12 X 35mm
Hex bolt
8X
M10 X 70mm
Hex bolt
2X
M10 X 80mm
Hex bolt
2X
M14 X 140mm
Hex bolt
2X
10
Flat washer
16X
12
Flat washer
8X
8X
14
12
Flat washer
2X
14X
nut M10
Hex lock
2X
nut M14
Hex lock
