SPECIFICATIONS
OVERALL DIMENSIONS
2
www. mechmaxx.com
SPECIFICATIONS
Engine
Model
Ducar
P4206
Engine Type Single cylinder,4 stroke, air-cooled,OHV
Engine Displacement
420cc
Horsepower
15hp
Chipping Dia.
Cutting method
Start
6 in
Drum
E-Start
Knives Nos. 2 x blade; 1 x anvil
Drive Dual V-belt
Clutch Centrifugal clutch
Feeding chute Standard
Discharge chute
360 degree rotating
Emergency stop Stop bar + button
Towing Tow bar with 2 ft coupler
Wheel Front 19*7.00-8; Rear 13*5.00-6 Tubeless tyre
Weight (N.W./G.W.) 569/629lbs
Package Method Plywood Case
Packing Size 42*31*45in
1453mm
72.0”
1217mm
41.2”
2764mm
99.4”
