When all options are ON, you will receive the following information listing for each option:
ALARM ON options explained below:
ALARM ON,1,2,3,4,5,6,7
1 Alarm Number Selected; 1, 2, 3, 4 or 5
2 x Limit1 value
3 x Limit2 value
4 B = Buzzer, L = LED, BL = Buzzer & LED
5 O = Out of Band, I = In Band
6 P = Pass, F = Fail
7 C = Continuous, P = Pulse, or blank
PLC ON options explained below:
PLC ON,L,1,2
L At limits
1 R = Reset, C = Continuous, P = Pulse
2 Limit value
PLC ON,A,1
A At alarm
1 H = High, L = Low
PASSWORD 1 options explained below:
PASSWORD 1
1 Menu Password ON or OFF
FREEZE ON options explained below:
FREEZE ON,1
1 L = Low, H = High
% TAMP EV ON options explained below:
% TAMP EV ON,1,2
1 Drop in percent
2 Load Transmitted, 1st for 1st peak, 2nd for 2nd peak, 1st&2nd for both
page 35
