AV TIME ON options explained below:
AV TIME ON,1,2
1 Start Threshold value
2 Stop Threshold value
RATE 1 ON options explained below:
RATE 1
1 M = Medium, H = High
FOOTSWITCH1 ON options explained below:
FOOTSWITCH1 ON,1
1 Footswitch 1 - M = Max, U = Units, T = Txd, Z = Zero, R = Reset
FOOTSWITCH2 ON options explained below:
FOOTSWITCH2 ON,1
1 Footswitch 2 - M = Max, U = Units, T = Txd, Z = Zero, R = Reset
COMMS 1,2,3,4,5,6,7,8
1 P = Port, M = Store in memory
2 Units being transmitted, ON or OFF
3 Sign being transmitted, ON or OFF
4 Baud rate value
5 C = Carriage return, L = Line feed, CL = both
6 Line delay in seconds
7 Constant transmit threshold in percent
8 S = Serial RS232, D = Digimatic, B = Both
COMMS settings are explained below:
page 36
