ActiveCare - Fixed
User Manual
MAN-ActiveCare REV02 ActiveCare Fixed USER MANUAL Page 20 of 25
3. Install fasteners and spacers back in actuator. Tighten the fastener so that the bolt
comes through the nylon nut but do not overtighten or the actuator will bind causing
damage,
Image from
underneath the bed
Actuator
Corresponding
locations to install
actuator
Actuator mounted
in “Left turn
Position”
Reinstall Spacers as
seen in the picture
