Med-Mizer FlexTilt TF16 - Adjustable Seat Height

FlexTilt FT16-FT24 User Manual
Revision 06
MAN-FlexTilt REV06 FlexTilt-FT20-FT24 USER MANUAL Page 9 of 13
8. Adjustable Seat Height – The seat height has three different heights that are available
(19.25”, 18.25”, 17.25”). Adjusting the seat height means moving the adjustment
brackets down or up as well as adjusting the cylinder to match the height.
Note: (The chair will always be delivered in the highest position.)
Highest Position
Adjustment
bracket in
highest position
Adjustment
bracket in
highest position
Cylinder in highest position
of locater bracket
Middle Position
Adjustment
bracket in
middle position
Adjustment
bracket in
middle position
Cylinder in middle position
of locater bracket
Adjustment
bracket in
lowest position
Adjustment
bracket in
lowest position
Lowest Position
