Troubleshooting
21
Possible Cause and Solution
1) Rotate the [VOLUME] knob to be sure that the volume isn’t down.
1) To be sure that the pad is connected correctly.
2) To be sure not set the volume of the pad to 0
1) To be sure not set the volume of the click to 0.
1) Turn down the volume.
Problem
No Sound
No Sound from Pads
No Click Sound
Sound is Distorted
Specifications
Maximum Polyphony
64
Drum Kits
10 Preset Kits
General MIDI Kits
5 GM Kits
Sequencer
30 patterns
12 drum loops
Resolution
192 ticks per quarter note
Tempo
30~280
Display
3-digit LED
Connectors
25-Pin Trigger Input Jack, Phones Jack, Aux In, Line
Output (R, L/MONO), USB MIDI, DC IN Jack
Pad Select Buttons
1 Snare Pad, 3 Tom Pads, 1 Crash Cymbal, 1 Ride
Cymbal, 1 Hi-Hat Cymbal,1 Hi-Hat Pedal, 1 Kick
Pedal
Power Supply
DC 9V
Dimensions (Sound Module)
147.1(W) × 183.3(H) × 111.7(D) mm
Weight (Sound Module)
0.5 kg
* All specifications and appearances are subject to change without notice.
