Medeli DP-268 - Side Panel and Pedal Box Assembly; Rear Panel Assembly

Set-upGuide
7
7.Screws6X30(X4)
8.Screws4X15(X5)Φ
11.Screws6X12(X2)Φ
Φ
4PCS
2PCS
5PCS
SidePanelandPedalBoxassembly
RearPanelassembly
Placethepedalboxonthetwosidepanelsandthenusescrewstofastenthesidepanels.
Fixtherearpaneltothesidepanelswith2screwsandtothebottomoftherearpanelwith5screws.
NOTE:
Pleaseusethescrewsthatbesupplied,donotusetheotherscrews.
