Medion LIFE E62003 - Transmitter Diagram

52
8) Micro USB charging port
9) ON/OFF: On/Off switch
10) Charging contacts
4.2. Transmitter
12
14
11
13
16
17
18
15
11) Keyhole hanger for wall mounting
12) AUDIO IN: Audio port (3.5 mm jack)
13) DC IN: Connection for mains adapter
14) Feet
15) Charging contacts
16) Operating LED
17) ON/OFF: On/Off switch
18) PAIR button
