19
Voltage at charging
Displays the current voltage value on the charger when
connected to the 12V circuit on the loading device.
Battery temperature
Displays the current battery temperature.
BMS Temperature
Displays the current temperature on the BMS control
board.
Number of battery cycles
One cycle corresponds to a full charge and discharge of
the battery to 100% capacity.
Overall internal temperature
Displays the current temperature inside the electrical
box.
Battery status
Displays the current capacity [%] and voltage [mV] of the battery.
Cell status
Displays the current voltage values of the most and least charged cells of the battery.
Position of the most (green)
and least (red) charged cell
Highest cell voltage
Lowest cell voltage
