Medisoft FeNO+ - 6.3 Maintenance procedures for the user; 6.3.2 Replacement of the pneumotachograph mesh

H11-EN Maintenance P
AGE 30/31
6
6.3 Maintenance procedures for the user
6.3.1 Cleaning
See dedicated manual for cleaning and disinfection.
6.3.2 Replacement of the pneumotachograph mesh
For devices that have the spirometry option.
Remove the pneumotachograph from the handle.
Take the pneumotachograph from the lower part and turn counter clockwise the
upper part in order to disassemble the pneumotachograph.
Carefully remove the mesh.
Carefully put the new mesh in place without touching the screen.
Assemble the pneumotachograph and reconnect it to the handle.
5
4
3
2
1
