Medisoft FeNO+ - Spirometry Option

H11-EN General overview P
AGE 9/31
3
3.1.2 Spirometry option
Front panel
Power LED
Main sampling port
Flow selector
Corrugated tube for exhaled air sampling
Antibacterial/viral filter
Handheld spirometer
Lilly type pneumotachograph
Combined tubing for handheld spirometer
Downstream flow connector (-,blue)
Upstream flow connector (+,red)
Heated wire connector
Holder for pneumotachograph
m
l
k
j
i
h
g
f
e
d
c
b
a
