NNUAL PM INSTRUCTIONS
PREVENTATIVE MAINTENANCE KIT
Final Check Procedure
Plug the DSD EDGE power cord into the power outlet. Ensure that the machine powers up correctly and is in an idle
position. NOTE: The unit is in the idle position when the Station A and Station B yellow LED indicators above and below
the LCD display are not illuminated.
Slowly open the incoming water supply valve.
Bleed the air out of the 0.2-micron filter by pressing SETUP, 43, ENTER. This will allow the main water valve (#14)
to open). Place a small container under the bleeder hose to collect the water. Slowly open the bleeder valve until all
air is purged from the filter and water freely flows. Close the valve.
Press STOP twice.
Place a restrictor adaptor into each basin connector.
The next steps will be performed once the unit is completely reassembled. Open the appropriate valve (detergent and
alcohol) for the side of the machine you are working on. Using diagnostics run the appropriate pump to prime the
system. Continue running the pump until fluid appears from the scope hookup or restrictor. Once fully primed, turn off
the pump and close the valve. Repeat the above process for the three remaining pumps.
Activating Side A Alcohol Pump:
Select Station A,
Enter diagnostics by pressing 88, ENTER. Input code 135, ENTER. Open the alcohol valve by pressing
0, ENTER
to access Valve Control. Then press
18, ENTER, 12, ENTER. Then turn the pump on by pressing 3, ENTER.
Once the fluid is seen coming out of the restrictor, press 0, ENTER to deactivate the pump and valve.
Activating Side A Detergent Pump:
While still in the valve control section of diagnostics, press 18, ENTER, 1, ENTER which opens the valve.
Then activate the pump by pressing 19, ENTER. Once the detergent is seen flowing from the restrictor,
turn off the pump and valves by pressing 0, ENTER.
To remove the fluid from the basin, press ADD AIR and START. Allow to run for about 30 seconds or
until the basin is drained. Press CANCEL and ENTER to cancel the procedure.
Activating Side B Alcohol Pump:
Select Station B:
Enter diagnostics by pressing 88, ENTER. Input code 135, ENTER. Open the alcohol valve by pressing
0, ENTER
to access Valve Control. Then press
18, ENTER, 12, ENTER. Then turn the pump on by pressing 3, ENTER.
Once the fluid is seen coming out of the restrictor, press 0, ENTER to deactivate the pump and valve.
Activating Side B Detergent Pump:
While still in
the valve control section of
diagnostics press 18, ENTER, 1, ENTER which opens the valve.
Then activate the pump by pressing 19, ENTER. Once the detergent is seen flowing from the restrictor, turn off the
pump and valves by pressing 0, ENTER.
To remove the fluid from the basin, press ADD AIR and START. Allow to run for about 30 seconds or until the basin
is drained. Press CANCEL and ENTER to cancel the procedure.
