Alterra 1232 Bed Parts List
Serial No. Item Number Quantity Description
1 FCE1232001 1 Locating square tube for head board
2 FCE1232002 1 Head section bed deck
3 FCE1232003 1 Seat section bed deck
4 FCE1232004 1 Foot section bed deck
5 FCE1232005 2 Foot section elevation bracket
6 FCE1232006 2 Leglift support
7 FCE1232007 1 Foot section H shape base
8 FCE1232008 1 Head section H shape base
9 FCE1232009 4 3" twin-wheel caster, non-locking
10 FCE1232010 4 3" twin-wheel caster, locking
11 FCE1232011 2 Elevation arm
12 FCE1232012 1 Baseboard bumper
13 FCE1232013 2 Head/foot section motor
14 FCE1232014 2 Hi-Low Motor
15 FCE1232015 4 Mattress retainer
16 FCE1232016 1 Hand pendant
17 FCE1232017 4 Head/foot board bracket
18 FCE1232018 2 Elevation crank
19 FCE1232019 2 Slide rail
20 FCE1232020 2 Mount plate
21 FCE1232021 16 Cotter pin
22 FCE1232022 2 Pin for hi-low motor 1.5" long
23 FCE1232023 4 Pin for hi-low motor 3.5" long
24 FCE1232024 16 M8 anti-slide screw cap
25 FCE1232025 2 Screw 5/16" x 35"
26 FCE1232026 4 Screw 5/16" x 28"
27 FCE1232027 24 Washer (45#)
28 FCE1232028 8 Screw wrap tube
29 FCE1232029 8 5/16" nylon screw cap
30 FCE1232030 2 Spacer sleeve
31 FCE1232031 4 Strap for crank
32 FCE1232032 2 Screw 5/16" x 35"
33 FCE1232033 1 Control box
