8 INSTRUCTIONS FOR USE
ENGLISH
5
6
7
8
9
10
11
Front view
5. Close the battery cover after
inserting the battery.
6. When inserting the batteries,
observe the +/- markings (bat-
teries included).
7. ON/OFF button: Press the ON/OFF
button to turn the device on.
8. Power indicator:
• The green light is on: Ongoing
operation
• The red light is on/flashing:
Low power/malfunction
• No light: Malfunction
9. Medicine cup connecting
tube: Connect it directly to the
mouthpiece
10. Spray mesh
11. Mask connecting tube (it can be
removed)
To avoid cross-contamination, each user should have their own set of
net nebulizer accessories. Additional accessories must be purchased
from your dealer or product manufacturer.
The device works with 2 AA alkaline batteries or by using a mains
adapter.
Mains adapter specifications: input: 100–240 V AC 50/60 Hz
output: 5 V DC, the users buys it from
a qualified manufacturer.
