TECHNICAL DATA
Displacement 37.2 cm2
Max. engine capacity 1.2 kW
Fuel Mixture of 40 parts of unleaded
petrol to 1 part of 2-stroke oil
Fuel tank capacity 310 ml
Saw chain oil Engine oil SAE10W-30
Oil tank capacity 190 ml
Carburettor Diaphragm type
Fuel consumption at
max throttle 500 g/kWh
Speed, no load 3000 ± 400 rpm
Max speed with bar
and chain 12000 rpm
Max chain speed 22.86 mps
Ignition system Capacitive ignition system
with ignition control
Spark plug NHSP LD L8RTF/BOSCH L8RTF
Lubrication system Mechanical piston pump
with adjuster knob
Sprocket, no. of teeth x pitch 6T x 0.375”
Size L400 x W26 x H270 mm
Weight (without bar, chain,
fuel or oil) 4.5 kg
Sound pressure level in working
position LpA 97.9 dB(A)
Uncertainty factor KpA 3 dB(A)
Sound power level LwA 107.7 dB(A)
Uncertainty factor KwA 3 dB(A)
Vibration
Front handle 6.24 mps2
Back handle 6.79 mps2
Uncertainty factor 1.5 mps2
SAW UNIT
Bar type Sprocket nose
Size 14”
Cutting length 330 mm (14")
SAW CHAIN
Type Oregon 91P or Sabre 91S
or Carlton N1C-BL
Pitch 0.375”
Link width 0.050” / 1.3 mm
COMBINATIONS OF
BAR AND CHAIN
Bar Chain
1 Oregon 140SDEA041 Oregon 91P053X
2 Kangxin PO14-50SR Sabre 91S053T
3 Qirui PO14-50SR Oregon 91P053X
DESCRIPTION
1. Chain
2. Bar
3. Kickback guard
4. Starter handle
5. Air lter cover
6. Lock nut
7. Choke lever
8. Catch for throttle lever
9. Rear handle
10. Throttle lever
11. Oil tank
12. Engine switch
13. Fuel tank
14. Front handle
15. Bar guard
16. Fuel primer bulb
FIG. 1
PACKAGE CONTENTS
1. Engine unit
2. Chain
3. Bar
4. Bar guard
5. Spark plug spanner
6. File
FIG. 2
