Meec tools 014477 - ASSEMBLY; FOLDING HANDLE; GRASS CATCHER; SPECIFIC USAGE OPERATIONS

EN
33
DESCRIPTION
1. Top handle
2. Safety catch
3. Electrical box
4. Locking lever
5. Safety key
6. Grass catcher
7. Mower deck
8. Upper cutting deck
9. Motor casing
10. Bottom handle
11. Cord retainer
12. Power switch handle
13. Wheels
14. Battery cover
15. Battery
16. Charger
FIG. 1
ASSEMBLY
FOLDING HANDLE
1. Fit the bottom handle on the cover with
the locking levers.
FIG. 2
2. Fit the top handle on the bottom handle
with the locking levers.
FIG. 3
3. Fit the cord retainer on the handle and
secure the cord.
GRASS CATCHER
1. Lift up the rear cover and hang the grass
catcher on the back of the product.
FIG. 4
2. Remove by lifting up the rear cover and
removing the grass catcher.
FIG. 5
HOW TO USE
ADJUSTING THE MOWING HEIGHT
1. The product has three mowing height
settings: 20, 35 and 50 mm. Set the same
mowing height for all the wheels.
2. Adjust the mowing height by pressing the
wheel forwards and then either lifting
or lowering it to get the required height.
Make sure the wheel is locked in the right
position.
FIG. 6
3. This adjustment is done for each wheel –
there is no central height adjustment on
the product.
SETTING THE HANDLE HEIGHT
1. The product’s handle can be adjusted
vertically to suit dierent users.
FIG. 7
2. When the mowing height is set to 20 mm,
the handle height can be adjusted between
three positions – 84, 92 and 98 cm.
FIG. 8
WARNING!
Switch o the product, remove the battery
and wait until all moving parts have
completely stopped before adjusting.
STARTING
1. Insert the battery.
2. Insert the safety key (5).
3. Keep the safety catch (2) pressed in.
4. Hold the power switch handle (12) pressed
