1. INTRODUCTORY ILLUSTRATIONS
1.1 Principal Parts
1 Coolant Pump 10 Hydraulic Blade Tension Set
2 Main Motor 11 Saw Frame
3 Pulley Cover 12 Guide Arm
4 Electric Control Box 13 Guide Arms Slide
5 Stock Tray 14 Quick Approach Rod
6 Chip Conveyance 15 Feed Assembly
7 Lift Cylinder 16 Slide Shaft
8 Water Trough 17 Feed Cylinder
9 Oil Tank 18 Vise
