MEGABRAS MTD-20KWe - English; Default Chapter; Table of Contents

5
Index
1. Description______________________________________________________ 6
2. Operating instructions _____________________________________________ 7
2.1. Panel controls ________________________________________________ 7
2.2. Output Terminals ~ ___________________________________________ 8
2.3. Internal battery _______________________________________________8
2.4. Battery status check ~_________________________________________ 8
2.5. Power supply source ~ ________________________________________8
2.6. Battery charge________________________________________________ 9
2.7. Measurement ranges _________________________________________10
2.8. Grounding resistance measurement______________________________ 10
2.9. Spurious voltages measurement ________________________________ 11
2.10. Soil resistivity measurement – Wenner Method ____________________11
2.11. Audible Alarm ______________________________________________ 14
2.12. Influence of grounding resistance of the auxiliary rods_______________ 15
2.13. Special considerations about grounding resistance measurements_____ 15
3. Equipment operation checking______________________________________ 17
4. Technical Specifications __________________________________________ 19
5. Warranty ______________________________________________________ 21
