Megger B10E User Manual

5
Specifications
Outputs (DC), CATII
COIL, CLOSING/BREAKING
Output voltage 24-300 V DC
Load interval Max 1 s (at currents over 50 mA)
Ripple 2% peak-to-peak of the preset
voltage
No-load voltage (V) Current (A) Load dependency
24 10 < 6 %
48 10 < 3 %
110 6.5 < 2 %
250 3 < 2 %
300 1.25 < 2 %
Outputs (AC), CATII
COIL, CLOSING/BREAKING
Output voltage 24-260 V AC
Load current Max 5 A
Load interval Max 30 min
Output DC, CATII
MOTOR
Output voltage 24-300 V DC (loaded)
Open circuit voltage
(V)
Current
(A)
Load voltage
(V)
Max load
interval (s)
44 18 24 20
48 12 40 60
48 18 30 20
120 12 90 60
120 18 70 20
240 6 200 60
240 9 185 20
Max voltage: Terminals to protective earth (ground)
Terminal Voltage
Coil closing 300 V DC, 260 V AC
Coil breaking 300 V DC, 260 V AC
Motor 250 V AC
Shunt 250 V AC
Trigger closing 8 – 15 V AC
Trigger breaking 8 – 15 V AC
SPECIFICATIONS B10E
Specifications are valid at nominal input voltage and an ambient
temperature of +25°C, (77°F). Specifications are subject to change
without notice.
Environment
Application field The instrument is intended for use in
medium and high-voltage substations
and industrial environments.
Temperature
Operating 0°C to +50°C (32°F to +122°F)
Storage & transport -40°C to +70°C (-40°F to +158°F)
Humidity 5% – 95% RH, non-condensing
CE-marking
LVD 2014/35/EU
EMC 2014/30/EU
RoHS 2011/ 65 /EU
General
Mains voltage 115 / 230 (135 / 250) V AC, 50 / 60 Hz
Power consumption 3300 W (max)
Protection Thermal cut-outs, +80°C (+176°F)
Short-circuit protectors at DC outputs
Dimensions
Instrument 350 x 270 x 220 mm
(13.8” x 10.6” x 8.7”)
Transport case 610 x 290 x 360 mm
(24.0” x 11.4” x 14.2”)
Weight 20.8 kg (45.8 lbs)
29.3 kg (64.6 lbs) with accessories
and transport case
Test lead set, with 4 mm
stackable safety plugs
2 x 0.25 m (0.8 ft), 2.5 mm²
2 x 0.5 m (1.6 ft), 2.5 mm²
8 x 2 m (6.6 ft), 2.5 mm²
Display LCD
Measurement section
Voltmeter – digital
Range 0 – 300 V DC, 0 – 300 V AC
Resolution 1 V
Inaccuracy ±1% of displayed value, DC
±2.5% of displayed value, AC
Current shunt 5 A / 50 mV ±0.5% (built-in)
14 B10E ZP-BG02E BG0140ME
5 SPECIFICATIONS
