Megger BM15 - Features and Controls

5
Features and Controls
Rotary Selector
Switch
Non Locking Button
(recommended option)
Locking Button
(Extra care must be
taken if this option is
chosen. See page 6)
Generator Handle (MJ15)
+ Terminal
Guard Terminal
- Terminal
To insert terminal plugs, push in - To release, twist a quarter turn and pull out
