SV Test
Test time set at 5 minutes only. Terminating the test prematurely may
cause some results to be displayed as - - -.
Note: A capacitance value reading is only available if the test has run for
more than one minute, and provided the reading was not over-range
27
DD Test
Default test time of 30 minutes, followed by a 1 minute discharge time.
Terminating the test prematurely still allows the test results to be
calculated and displayed.
Note: A capacitance value reading is only available if the test has run for
more than one minute, and provided the reading was not over-range.
Timer
T3
Test Duration
T3 time
T3 time
T3 time
T2 time
T3 time
Digital Indicator
Blank
DD value
R at T3 time
I at T3 +1 minute
PI (T1 / T2)
µF
Voltage Indicator
Final test voltage
Voltage at T3 time
Voltage at T3 time
Voltage at T3 time
Voltage at T2 time
Voltage at T3 time
Other
DD cursor
flashes
PI cursor
flashes
Timer
Test Duration
1,00 minute
2,00 minute
3,00 minute
4,00 minute
5,00 minute
Test Duration
Digital Indicator
Blank
R (at 1 minute)
R (at 2 minutes)
R (at 3 minutes)
R (at 4 minutes)
R (at 5 minutes)
µF
Voltage Indicator
Final test voltage
Voltage at 1 minute
Voltage at 2 mins
Voltage at 3 mins
Voltage at 4 mins
Voltage at 5 mins
Final test voltage
