Maximum Specimen Capacitance
Table 1 shows the maximum measurable specimen capacitance at various
voltages and loading time. This can be increased up to 1.2µF at 10 kV (50 Hz)
test voltage using the optional Resonating Inductor.
Table 1: Maximum Measureable Specimen Capacitance at 50/60Hz
Test
Volts
(kV)
Maximum Capacitance
(µF)
(100 mA continuos
service)
Maximum Capacitance
(µF)
(300 mA for 4 minutes)
60 Hz
50 Hz
60 Hz
50 Hz
0.025
11
13
32
38
0.05
5.3
6.3
16
19
0.1
2.6
3.2
7.9
9.5
0.25
1.1
1.3
3.2
3.8
0.5
0.53
0.63
1.6
1.9
1
0.26
0.32
0.79
0.95
2
0.13
0.16
0.40
0.48
3
0.09
0.11
0.27
0.32
4
0.065
0.080
0.20
0.24
5
0.11
0.063
0.16
0.19
6
0.044
0.055
0.13
0.16
8
0.033
0.040
0.099
0.12
10
0.027
0.032
0.080
0.095
12
0.022
0.027
0.066
0.080
ALL FREQUENCIES AND LIMITS ARE LISTED IN SECTION 3 –
FREQUENCY SPECIFICATIONS
